Athearn G65931 HO GP50 Chicago & North Western #5091 With Sound

GP50 LOCOMOTIVE FEATURES:
• Full cab interior • Wire grab irons
• Coupler cut levers • See-through cab windows
• Flexible rubber trainline hose • Flexible rubber MU hoses
• Etched see-through steps • Walkway tread
• Lift rings • Sander lines
• Windshield wipers
• McHenry® scale knuckle couplers – Kadee compatible
• Accurately-painted and –printed paint schemes
• Fully-assembled and ready-to-run
• DCC-ready features Quick Plug™ plug-and-play technology with 21-pin
NEM connector
• Scaled from prototype resources including drawings,
field measurements, photographs, and more
• Fine-scale Celcon handrails for scale appearance
• Detailed fuel tank with fuel fillers, fuel gauges, & breather pipes
• Genesis driveline with 5-pole skew wound motor, precision machined
flywheels, and multi-link drivetrain
• All-wheel drive with precision gears for smooth & quiet operation
• All-wheel electrical pickup provides reliable current flow
• Wheels with RP25 contours operate on all popular brands of track
• LED lighting for realistic appearance-including lit number boards,
ground lights, and marker lights (if applicable)
• Heavy die-cast frame for greater traction and more pulling power
• Packaging securely holds model for safe storage
• Minimum radius: 18” — Recommended radius: 22
PROTOTYPE SPECIFIC INFORMATION
The EMD GP50 is a 4-axle diesel road switcher locomotive built by General
Motors Electro-Motive Division between 1980 and 1985. It is powered by a
16-cylinder EMD 645F3B diesel engine, which can produce between 3,500
and 3,600 hp.
A total of 278 examples of this locomotive were built. The GP50 retains
the same overall length of 59 feet 2 inches as the other GP dash-2 series
locomotives built in the same era. It utilized GM’s D87 traction motor enabling
it to produce a starting tractive effort of 65,000 pounds, with a continuous
rating of 62,400 pounds.
The most significant difference in the GP50 from earlier designs like the GP40
was upgraded components (like a turbocharger silencer and new type of
blower housing) and increased horsepower. The locomotive also introduced
a new “anti-wheel-slip” technology where the locomotive horsepower output
was reduced if a wheel slip condition was introduced. It also included features
already common on earlier models such as dynamic braking (a system for
temporarily employing traction motors as generators and using the resulting
electromotive force to slow the train), and an airtight hood that kept out dust,
dirt and other particles from reaching internal components.
All the companies that purchased the GP50 have now been absorbed into
other systems. However, a few of their successors continue to operate the
units. A number GP50s have rebuilt for better fuel economy and continue in
service today.
This page is based on the copyrighted Wikipedia article “EMD GP50”
(https://en.wikipedia.org/wiki/EMD_GP50); it is used under the Creative
Commons Attribution-ShareAlike 3.0 Unported License (CC-BY-SA). You
may redistribute it, verbatim or modified, providing that you comply with the
terms of the CC-BY-SA.
SOUND-EQUPPED MODELS ALSO FEATURE
• Onboard DCC decoder with SoundTraxx Tsunami2 sound
• Dual cube speakers for optimal sound quality
• Sound units operate in both DC and DCC
• Full DCC functions available when operated in DCC mode
• Engine, horn, and bell sounds work in DC
• All functions NMRA compatible in DCC mode
• Precision slow speed control
• Program a multiple unit (MU) lashup with lead unit only horn, bell, and lights
• Many functions can be altered via Configuration Value (CV) changes
• CV chart included in the box
CNW FEATURES:
• Phase I Body • Nose-mounted “Gong” Bell
• Winerization Hatch • Small EMD plow
• Leslie 3-chime horn • Sinclair antenna
• Western Cullen style beacon (Operational in DCC)
